INCLUDED: Reliable ÜberLight Flex 3100TL LED Task Lamp with Clamp

Product Description

Thread Trimming & Needle Positioning
The 5000SD single needle, drop feed sewing machine adds advanced functionality with a direct drive servo motor, automatic thread trimming, back tack functions and stitch programming features.

Labor Saving = Time Saving
For the busy sewing workroom or factory, time is money and the labor saving thread trimming and positioning features in the 5000SD provide a proven payback, not to mention the added convenience and ease of use of these advanced features.

  • 5,000-RPM high-speed operation
  • Operator’s LED lamp
  • Presser foot spring regulator
  • Built-in bobbin winder with thread cutter
  • Disable presser foot drop after thread trimming
  • Electronic thread clamp
  • Trimmer disable
  • Needle positioning up/down

    Direct Drive Servo Motor
    The 5000SD features a built-in direct drive servo motor that harnesses the latest technology. This motor allows for quieter and smoother operation.

    Digital Control Panel
    Programming your 5000SD is within arm's reach. You can change the speed of the motor and set the needle positioning.

    Automatic Back-tack
    With the 5000SD, you can press the back-tack button to automatically lock the stitch, saving you time when you need it.

    Foot Lift and LED Lighting
    With a large clearance, the foot can be lifted up to 13mm. Built-in, bright LED lights illuminate the sewing path and provide an optimal workspace.

    Built-in Bobbin Winder
    For added convenience, the bobbin winder on the 5000SD is built-in to the top of the machine head.
  • US Warranty 1 year parts, 90 days labor on defects in materials and workmanship.
  • Non-US Warranty: 30 days parts and labor
Specifications
Maximum Sewing Speed: 5,000 RPM
Stitch Length: 0 – 5 mm
Needle Bar Stroke: 31 mm
Pressure Foot Lift:
-By hand: 5 mm
-Automatic: 13 mm
Needle System: #16 x 257
Feed Dog: Single row
Hook Type: Rotary (auto lubricated)
Lubrication: Automatic
Stitch Dial Regulator: Yes
Reverse Lever: Yes
Country Of Origin: China
Warranty: Limited 1 year
