• 18” deep X 10” high

• Built in bobbin winder

• Auxiliary hand wheel

• THREAD TRIMMER!

• Semi Dry head technology

• Direct drive servo motor

• Metal gear timed

• Auto tie off feature

• Basting stitch

• And MORE

  Information Below Applies Only to QVP Frame Model, not to Sit Down Model. Handles are not included and not needed for free motion quilting where you are moving the fabric under the needle.

  "Just took the Long Arm quilting class at Allbrands and it was awesome. The teacher Kay was so great and full of knowledge. Once you take the class you can rent the machine by the hour to quilt your own quilts!! Sign up, you won't regret it!!" Lisa M

  Direct drive motor with metal gears without any belts makes the machine more responsive and quieter. Specifically the motor is built into the head on the main shaft and the lower shaft is turned by a gear, there is no belt noise.

  It has 18x10" or 180 square inches of arm space, compared to 118" for Tin Lizzie 18x6", 144" for Handiquilter Avante 18x8", and 144" for Tin Lizzie 24x6" heads. That's 25% more arm space more than 18x8 or 24x6 arms.

  The touch screen panel has many options. Automatic stitch regulation or manual speed control, up to 16 spi stitches per inch on stitch regulation. Needle programmed to always stops up or always stop down, automatic thread trimming or manual command, etc.


• 18.25" x 10.25" oversize arm space to right of needle is the largest workspace of any 18" longarm on the market. (55% more workspace than Tin Lizzie 18x6" Arm. 25% more than HandiQuilter Avanti).

• Side Mount Hand Wheel eliminates the need reach around to the back of machine for main hand wheel.

• Independent M bobbin winding system allows winding bobbins while sewing, or when not sewing.

• Front or back operation of the machine from front or back of quilting frame. Free motion from the front and pattern motion from the back with laser stylus included and optional quilting design templates or paper patterns on the table.

• Grace All Metal 10 foot 120" frame a $3000 Value (expandable to 12 foot 144" frame with optional extension kit)

• Stitch Regulator with X and Y encoders for the machine and platform which comes with machine.

• Cruise Control Speed Settings as a % of 2200SPM maximum.

• 6-16 Stitches Per Inch Settings for Stitch Length using Stitch Regulator

• Baste to 3SPI Stitches Per Inch (1/2" 1" and 1.5"),

• Presser Foot Adjustable Height for Fabric and Batting Thicknesses, 0-4mm with Slotted Presser Foot Height Adjustment

• 0.5mm Recommended Distance from Bottom of Foot to Needle Plate when Foot and Needle are in lowest position. Adjustable for quilt thickness to prevent fabric from flagging (riding up and down on needle.)

• 1/4" Tall, 1/2" Diameter All Metal Presser Foot for Rulers and Visibility.

• Tack or Stay Stitch to make three stitches in place, and stop with needle up or down.

• Needle Up or Down Settings will always stop with needle in fabric, or needle out of fabric

• Needle Eye Guard to be installed at time of machine set up.

• Presser Foot Lever to be installed at time of machine set up.

• Two spool thread stand to be installed at time of machine set up.

• Automatic or Manual Activation of both Top and Bottom Thread Trimming at the same time, the only quilting machine on the market with these features.

• Super Bright LED No-heat lights above needle (4) and on both left and right handles (3 each).

• Machine Bed Size: 18.25x10.25" (187 square inches) between needle and neck of machine

• Speed: 2200 SPM Stitches Per Minute Maximum Speed Settings. Highest in Manual Free Motion Mode

• Machine Head Weight 26Kg or 57 Pounds

• Compatible with $5000 Grace Quilt Motion, Grace $2000 Creative Touch Pad Upgrade, Robotic Quilting Systems.

• Optional Set ups in 5' 60" Crip, 7' Queen, 10' 120" King 10'

• Batting Rail Included

• Quick Release system for Rails, including those with rachets or tensioners.

• Adjustable quilt frame leg Height up to 7" difference

• Optional 2ft Extension to do 7" or 84" and 12' or 144"


  ---

  Unique Design
  The Quilt Virtuoso Pro has a slim sleek and sturdy design, unlike any Long Arm Quilting Machines to date!

  Extra Large Throat Space
  Discover the impressive 18 inches of horizontal throat space between the arm of the machine and the needle. Even more impressive is the 10 inch height, unlike most long arm quilting machines which only provide 6 to 8 inches of height

  Bright LED Lights
  10 Ultra Bright LED Light Bulbs over the needle and pattern area illuminate your workspace like never before, making it easy to see detailed work, while simultaneously reducing strain on your eyes.

  Built-in Scissors
  Convenient automatic scissors simultaneously trims the top and bottom thread. No other Long Arm Quilting Machine has this feature!

  Ergonomic Handles
  The QVP comes equipped with ergonomic handles for ease and comfort while quilting. The ergonomic handles swivel from vertical into horizontal micro handles for precise close up detailed work! No need for extra set of micro handles.

  Needle Up/Down
  Easily move the needle up or down with the included Needle Up/Down Button. If the machine is off you can use the easy to reach hand wheel on the front of the machine allowing you to raise and lower the needle without having to turn on the machine or reach all the way around to the wheel on the back of the machine.

  Independent bobbin winder/motor
  The built-in bobbin winder has its own motor independent of the machine, so you can wind bobbins while you continue to quilt or while the machine is idle.

  Ultra Glide Tracking System
  Eight Ball bearing wheels hug the track of the frame in a V shape, ensuring smooth even quilting at all times.Machine will not "jump" off the rails.

  Take-up Bar
  The take-up bar allows you to roll up your quilt all the way without making any adjustments to the frame, unlike most other quilting machine frames where you have to adjust the rails up and down as the quilt fills the machine throat. Idler or dead bar below take up bar holds the fabric down to the bed to prevent flagging of fabric which causes skipped stitches.

  Made in Japan
  The QVP is made and assembled entirely in Juki's leading industrial manufacturing plant in Japan - not in China or Taiwan. It used technology developed for Juki's line of industrial sewing machines which have been proven benchmarks for decades of production and use. The All Metal Frame is made by Grace in Salt Lake City, Utah.

  Leader in sewing and quilting
  Juki is the Leading manufacturer of industrial sewing machines worldwide. Juki has taken this industrial knowledge and experience and put it into this long arm quilting machine for home use. The result is a unique heavy-duty high quality long arm quilting machine that all quilters are sure to love. 400W Motor is the strongest in the industry.

  2,200 SPM Stitches Per Minute Maximum Sewing Speed
  Obtain faster results! The TL-2200QVP offers professional speed so you can complete projects in record time. You can quilt faster on a Juki QVP than any other quilting machine made for the home market.

  Stitch Control - Perfect Tension Balanced Stitches
  The stitch balance control allows you to deliver more consistent stitching according to your needs for a perfect finish on your quilt. Pretension knob guarantees correct length of thread tail after thread trimmer is activated.

  Built-in Stitch Regulator
  Start, stop, speed up and slow down the motor of the quilter delivering the exact amount of stitches per inch that you have set in with the built-in stitch regulator on the TL-2200QVP Quilter. 10-12 SPI Stitches per Inch Recommended.

  Four Stitching Modes
  Work on your project the way you see fit! With three different stitch modes (Cruise doesn't stop stitching, Precise stops stitching when you stop, Manual Free Motion up to 2200SPM, and Baste for .5 to 1.5" stitch length) you can set up your stitching preferences and obtain the results you are looking for without added effort.

  Large 3.5" Color Touch Screen LCD Display
  Maintain absolute control with a top of the line Color LCD touch panel display where you can manage the stitch regulator, light settings, needle speed, stitch length, sound, screen brightness and all you need to complete your masterpiece.

  Automatic Thread Trimmer
  The machine is equipped with an automatic thread trimmer device that simultaneously trims the needle and bobbin threads to 1/4" at the sewing end by lightly pressing the push-button. It uses the same industrial thread trimming mechanism that was invented by Juki for their high speed straight stitch machines starting with the DDL555 to DDL8700 and has been in proven use for decades.

  Adjustable Front and Optional Rear Handles
  Added comfort and maneuverability with the adjustable front and optional rear handles that will give you complete control over your project from any position around the machine. Front handles are used for free motion quilting. Read handles can be used for following patterns with laser stylus included.

  Handle Bar Controls
  Start/Stop with Right Handle Button - Needle Up/Down with Left Handle Button. Controls at the reach of your finger tips.

  Compatible with ¼ Inch Thick Rulers because the presser foot ring is 1/4" tall

  All Metal Solid Steel Heavy Duty Virtuoso Frame by Grace Frame

  Internal Motor
  Internal motor provides a quiet smooth operation, without any belt/noise.

  Dry Head System
  Thanks to the advanced dry-head technology (4 sealed permanent lubrication metal bearings on main shaft and 5 silicone impregnated and brass bushings throughout rest of machine) no lubrication is required except for the rotary hook section before each quilting project. This eliminates oil stains on the sewing product.

  Quick Response Direct Drive Motor - No Drift and No Belt to Slip
  For quiet and smooth operation.

  Easy Access Auxiliary Hand Wheel
  Obtain faster results! The TL-2200QVP offers professional speed so you can complete projects in record time.


  ---


  You can register your Juki machine purchase online with our new Registration page. Click here to Register.

  Juki QVP Product Brochure(.PDF)

  Juki QVP Longarm Sewing Machine Instruction Manual(.PDF)

  Juki Parts and Service Instruction Manual(.PDF)

  Juki QVP Instruction for Presser Foot Lift Installation(.PDF)



  ---



  Description & Specifications
  Sewing speed: Max. 2,200SPM Stitches Per Minuet
  Needle bar stroke: 35mm
  Lift of presser foot: 5.5mm
  Needle: GB, Organ or Schmetz 134R and equivalents.
  Lubricating oil: New Defrix Oil No.1, or any clear sewing machine oil.
  Dimensions of sewing machine: 22.2W x 46.0H x 73.0L (cm)
  Weight of sewing machine: 26 kg. 57 Pounds
  Rated power supply / Power consumption: 120V/140W 60Hz

  Please review our Freight LTL Shipping Policies Ships Ground Freight only.* For delivery please select options. "Lift Gate" which means a goods lifting platform installed at the rear of the delivery truck that facilitates the unloading of cargo from truck bed to the ground. Most shipments will require a lift gate, if there is not a loading dock, or fork lift available for delivery.

  "Miyabi" Juki J-350QVP Arrives by Rob Appell
  The Studio is almost finished as Rob Appell builds a serious power tool. Have fun watching Rob assemble the frame and of course a bit of skateboarding too. The Juki J350 Stand Up Mid Arm Quilting Machine will be a great addition to Making it Fun!

  Preview the New Juki MIYABI J -350QVP Longarm - JukiLongarmQuilting.com



  Juki Tech Brian Debrick and National Educator Karen Pharr train AllBrands staff on QVP April 19, 2013







  Attaching fabric to a Grace Quilting Frame Video:


• Adjust individual needle speed from 400 to 1000 Stitches Per Minute.

• 10 Thread Eyelet Threading System eliminates tangles and and maintains Consistent Tension. Perfect tension on all 10 needles

• 10 Needle Auto Threading from Any Screen

• 10 Full Spectrum LED Lights above needles has the brightness of 35 light bulbs and eliminates shadows.

• 10 Thread Colors on Lighted Spool Stand

• 10 Lights in the InnovaChrome LED Thread Color System. LED Lights below each of 10 spool pins on the thread stand are color coded to match 10 of up to 300 thread colors shown on the screen. So you can never mismatch thread spool color indicated on the main control panel. These lights also flash to advise of thread color change, thread breakage, design completion, and empty status.

• No need to babysit your machine

• Extra Large 30x15" Extension Work Table

• 4 Flat Hoops up to 8x14"

• 110 Built-in Exclusive Embroidery Designs.

• 35 Fonts, Alphabets and Monogram Styles

• Color palette, 300 colors for visual indication of correct thread color

• InnovEye® Technology and Snowman Embroidery Positioning Marker from Quattro NV6000D: built-in camera above the needle that is sewing. Precise positioning of your center and starting point is easy with the 200% actual size zoom and visual grid function. Use the InnovEye to view any thread breakage point, then select the grid function to determine the spot to restart your embroidery.

• Snowman® Embroidery Precise Positioning Marker using needle camera for perfect placement, matching the angle of your embroidery to the angle of your hooped fabric.

• Link up to four PR-1000 or upgraded PR-650 machines to one computer

• Queue up to 100 designs

• Built-in memory: 1.7MB; save up to 500,000 stitches to memory

• Built-in tutorial movies, diagrams and instructions

  Impressive 10-color, 50,000 stitch-count designs can be completed 12% faster than with a six needle machine, and more than 30% faster than with a single-needle machine. With the PR-1000, you truly can enter the next dimension in creativity and productivity.

  10 Thread Eyelet Threading System

  The PR-1000 promises virtually perfect thread tension every time with the Eyelet Threading System, a Brother® exclusive.

  Perfection is all about consistency, and the exclusive Eyelet Threading System from Brother provides both.


• Maintains consistent tension on all 10 threads, even as the needle bar moves

• Virtually eliminates thread tangling, even in drafty environments

• Requires no tools—follow a simple, numbered path

• Eyelets slide open and closed for added thread control

  10 Needle Auto Threading

  As the only multi-needle machine with a built-in automatic needle threading system, you'll thread each needle in seconds — with just the touch of a button!

  See thread pass effortlessly through the eye of each needle. No more struggling to thread the needles!

  10 Thread Colors

  Defy embroidery as you've always known it by stitching designs up to 10 colors without changing thread. Many 20-color designs can be completed with just two thread changes.

  And for variety, switch to monochrome mode to stitch multi-color designs as one color designs.

  10 Lights in the InnovaChrome LED Thread Color System

  The color selection and threading of a multi-needle embroidery machine has never been so intelligent! The InnovaChrome™ LED Thread Color System is the first of its kind, and as you'll see, IT'S simply amazing!

  Underneath each of the 10 thread spools is a full color LED light which mimics the color of the thread that belongs on the spool for each design, eliminating any guesswork as to what color thread should be used.

  Thread selection has never been so easy—or fun!


• Match the thread colors needed in your designs, using the LED under each spool.


• The LEDs are calibrated to indicate the closest color from the hundreds of colors used in standard design color palettes.


• LEDs correlate to thread color information shown on the LCD screen.

  No need to babysit your machine



  The lights also double as a visual status system so you can spend less time supervising your machine.

  Different light and built-in audio cues communicate:


• Thread color change

• Thread breakage

• How much of your design is finished

• Completed designs

  When your design is finished, the InnovaChrome™ System calls you back to the machine with a special light show. The lights even flash just to say “Hi” when you turn the machine on!

  Videos on Brother PR1000 Perfect 10 Embroidery Machine PR1000 Videos on You Tube

  Brother Free Firmware Updates for PR multi needle embroidery machines to recognize the new PRMS360 Hoopnetic Magnetic Sash Frame for PR1000, PR1000E, PR1050X, PR1055X, PR670E, PR655:Version 4.40 Software Update Now Available for the Entrepreneur Pro PR1000E/PR1000. Click here to download the new software update.

  We would like to inform you we have released several software updates for the Entrepreneur Series on Brother Solutions Center. Updating your 6-needle or 10-needle embroidery machine with this software will provide you with the ability to use the new Hoopnetic Magnetic Sash Frame.

  PR1000e and PR1000
  Version 4.40
  The optional embroidery frame Magnetic Sash Frame (PRMS360) can be recognized on the machine.
  The maximum embroidery area available for this machine is 360mm x 200 mm (14 inches x 7-7/8 inches).

  Click here to download the new software update.

  Brother™ Entrepreneur® Pro PR1000e 10-needle Home Embroidery Machine Overview


  Brother Entrepreneur Pro PR-1000 Overview | Introduction


  Optional PR10 Upgrade Kit



  Google Videos on Brother PR1000 10 Needle Embroidery Machine

  You Tube Videos on Brother PR1000




• QuiltMotion takes you seamlessly through pattern design to stitching with absolute ease.

• QuiltMotion comes wit a motor plate and hardware that attach to your sewing machine and quilting frame.

• QuitMotion lets you place your patterns on quilt the exact way you want, even if you have to stretch or skew a pattern.

• QuiltMotion's quilt design software comes with a library of over 200 patterns to choose from.
  You design it, QuiltMotion quilts it

  Juki QuiltMotion and Quilters Creative Touch Computerized Quilting System is the computer automated quilting at its best

  Experience the simple yet overall incredibly complete package. Enjoy unique, all-inclusive software - simple, and quilter-friendly. Digitize, size and create your blocks, pantographs, borders and full quilt layouts.

  QuiltMotion takes you seamlessly through pattern design to stitching with absolute ease. It is so awesome to watch your Juki 2200 QVP stitch out the designs you created. QuiltMotion brings together all the aspects of the quilting process, seamlessly taking you from IDEA to DESIGN to REALITY.

  Digitize and design unlimited patterns utilizing simplified techniques including tracing, mirrors and optimization.

  Size and create your blocks, pantographs, and borders to the exact dimensions of your quilt. Precisely place your patterns on your quilt with one of several placement methods. This version of QuiltMotion is made specifically for the Juki 2200QVP. It includes Quilter's Creative Touch. You receive everything you need to mount your Windows 8 Computer Tablet, which you supply, to your Juki 2200.

  With QuiltMotion/Quilter's Creative Touch, your tablet becomes the touch screen and you control everything from the tablet.

  Quilter's Creative Touch Design Software

  The Quilter's Creative Touch Design Software includes the basic functionality of Quilt Motion with a newly designed user interface and many new user friendly features.

• Designed for, and works best with Tablets which can be easily attached to your machine (Sold Separately). No computer or laptop needed.

  Powered by Quilt CAD!


  Pattern design Library

• Comes with 200 built in Quilting designs

• Import designs from other sources

• Create your own designs on your tablet, and save them into the library

  Pantograph Creation with "Panto Stacker"

• Alternate Rows, Sizing, and Number of Patterns can be edited in a few simple clicks.

  Fonts

• Add a Unique element to your quilt by including text and fonts from your system.

  Split Patterns with Virtutal Longarm (Patent Pending)

• No matter the size of your Sewing Machines throat or arm size, create large designs by splitting your pattern.

  Photo Trace

• Import photos and trace them to use as patterns


  QuiltMotion Computer Automated Quilting Hardware

  Works with your existing Sewing Machine and Quilt Frame Combo. This software and hardware combination offer allows you to create free motion quilt designs, and your machine will drive and stitch out the pattern automatically with precision.

  Computer Automated Quilting Powered by QuiltCAD









  **Click Here to View the Quilt Motion Compatibility Chart, *Brother, Babylock, Bernina, Janome, Elna, Juki, Pfaff, Viking. (.PDF)

  Quilt Motion Help & Troubleshoot File(.PDF)

  Installing the QCT 5 Quilting Automation Software and Hardware




• improved Advanced Super View (ASV) HD LCD touch screen display by Sharp® Corporation

• LCD adjustment feature allows you to change the brightness of the LCD display

• Enhanced design & editing features including group/ungroup feature, individual stitch backup and thread spool reset

• Improved, energy efficient LED lights have no mercury and consume 15% less power than before

• Choose from an expanded library of built-in designs and fonts or download exclusive designs from www.ibroidery.com

• Built-in link-ready function so you can streamline the operation of four machines with just one computer

  Easy Embroidering With 6 Needles And Automatic Needle Threading
  Embroider multicolor designs quickly and easily. At the press of a button, the thread is pushed through the eye of the needle.

  Advanced Super View (ASV) HD LCD Touch Screen By Sharp® Corporation
  • View your designs in crisp, sharp clarity on the 4.4" x 7.3" touch screen
  • 16.7+ MILLION possible colors with little or no color shifting
  • Enhanced viewing angle of 176 degrees vertical and horizontal
  • Almost instantaneous design rendering—no more waiting to preview your designs
  • adjustment feature allows you to change the brightness of the screen to suit your room’s lighting environment or for better viewing of light designs, such as lace
  • IMPROVED LED lights consume 15% less power, making it energy efficient
  • Customizable screensaver so you can promote your business while demoing

  Built-In Link-Ready Function* - Perfect For The Small Business Owner
  Link up to four PR650 Series and PR1000 Series machines (Optional PE-DESIGN® NEXT software required)
  • Monitor all machines from a single computer
  • Queue up to 100 designs

  Group/Ungroup Feature
  Combine designs and edit them as one, or separate design elements and edit pieces separately.

  Improved! Individual Stitch Backup
  Back up through designs by individual stitches, color blocks or groups of 500 stitches (an increase of 400 stitches).

  Stitch With Confidence Using The Basting Function
  Apply a basting stitch outline to the perimeter of any design to hold the fabric to the stabilizer. Great for larger fabrics and hard-to-hoop items.

  Expanded Library Of Embroidery Designs And Fonts
  • 25 built-in embroidery designs
  • 25 size-adjustable embroidery lettering fonts
  • Greek, Appliqué, Floral and Renaissance alphabet designs
  • 3 monogramming font styles, and 15 coordinating accents
  • 10 frame designs


  Large Embroidery Area Of 12" X 8"
  Includes four sizes of embroidery frames: 12" x 8", 5" x 7", 4" x 4" and 2" x 1.5".

  Three USB Ports
  High speed port for fast design transfers. A second port for machine peripherals. A third port for computer connectivity and future upgrades

  Adjustable Embroidery Speed Up To 1,000 Stitches Per Minute
  Save time when embroidering large projects.

  Automatic Color Changing And Thread Trimmer
  Pre-program the correct thread color sequence for the entire design. The upper and lower automatic thread trimmers mean no time-consuming trimming after the embroidery is complete.

• Large 10.1" built-in high definition LCD display with faster processing than prior models

• 9.5" x 9.5" embroidery frame with rubber gasket and ribbed corners for less slippage

• ScanImation™ Scanning Frame and InnovEye® 2 Technology

• My Design Center features: outline recognition to effortlessly add stipple and fill patterns to embroidery designs, and inside & outside auto stipple and fill patterns

• Easily create trapunto-like projects using the save outline feature

• Color Sort feature to cut down on thread changes when combining designs

• No-fuss stippling in the embroidery mode, easily adds stippling around any embroidery designs

• Easy appliqué feature with ability to create multiple appliqués in one hoop

• Enhanced embroidery editing features include: letter insertion at mid-point of a text line, left, center and right alignment

• Expansive 5" x 11.25" workspace for your larger projects and our largest 9.5" x 14" embroidery area

• 982 built-in embroidery designs, including 166 designs featuring Disney characters, 140 frame pattern combinations, 22 embroidery lettering fonts and 5 sewing lettering fonts.

• 726 built-in sewing stitches, including 15 styles of one-step auto-size buttonholes and 1 style of four-step buttonholes.

• MuVit™Digital Dual Feed System to powerfully feed fabric from the top and bottom for greater control

  Already Own THE Dream Machine? Click to learn about the available upgrade to receive all the features found in THE XV8550D Dream Machine 2. Includes 9.5x9.5" Largest Square Hoop.

  NEW Brother accessories online catalog by machine model numbers

  See Brochure o Brother XV8550D

  Read Instruction Manual on Brother XV8550D

  Watch XV8550D Video


  Even More Features: In this video, discover some of the amazing features of the Innov-IS XV8550D, such as the text alignment feature, grouping and un-grouping multiple letters/designs at once, and making multiple appliques in one hoop!


  Includes 9.5" x 14" Embroidery Area, and Industry First Features! Exclusive Camera and Scan, 10" LCD is 2x Faster Loading Time, Drop Light LED Laser Pointer for Embroidery Positioning

  *Up to 48 Months GE Synchrony Bank Fixed Payment No Interest Financing with approved credit! Transaction Code 448 Click HERE to Apply Online for Synchrony Bank Credit Approval

  Do you own a camera? Would you like to embroider with photos? Do you own a scanner- how about creating your own designs using a scanning bed on a machine. Did you ever auto digitize your designs using a software program? How about having a machine do it all for you? Create your own stippling inside or outside a design or all over the block the full length of the hoop which by the way is 9.25" x 14". You can even create intricate quilting stitches & designs without software using the DREAM machine.

  Your dreams... and ours are made real through a bounty of refined features captured in THE Dream Machine™. Our most powerful, technologically advanced combination machine includes 100 improved features. THE Dream Machine™ awakens your creativity as it allows you to construct your designs on our largest workspace ever. Dream bigger with our largest embroidery area, create in a wealth of design and editing options and envision it all with the industry's largest build-in HD display.


• 10.1" largest high definition LCD display in its class with faster processing time than our prior models

• Expandable library of over 40 built-in HD tutorial videos

• Expansive 5" x 11.25" workspace for your larger projects

• InnovEye® 2 our camera-like technology now with up to 2x the scanning speed and up to 3x the resolution

• Our largest 9.5" x 14" embroidery area illuminated with our brightest lighting system

• Industry-first My Design Center offer design capabilities all without a PC

• Auto Punch feature to turn just about anything into embroidery

• Line Art Scan and Embroider

• Scan & Stipple with Ease

• MuVit™Digital Dual Feed System to powerfully feed fabric from the top AND bottom for greater control

• Couching foot system to add cording techniques to your projects

• Sew Straight™ 2 Laser Vision Guide with brighter guide and wider range that extends up to 19mm

• Enhanced Color Shuffling™ 2 Function lets you choose your color palette for even more design possibilities

• InnovaChrome™ LED Thread Color System indicates color changes as well as thread breakages and alerts

• Droplight™ LED Embroidery Positioning Marker

• V-Sonic™ Pen Pal for Sewing and Embroidery

• Enhanced embroidery functionality, embroidery arm support, and improved embroidery frame

• 939 built-in embroidery designs including 166 designs featuring Disney characters, 140 frame pattern combinations, and 22 embroidery lettering fonts

• 726 built-in stitches, including 15 styles of one-step auto-size buttonholes, 1 style of four-step buttonhole, and 5 sewing lettering fonts

  THE INDUSTRY'S LARGEST BUILT-IN HIGH-DEFINITION LCD DISPLAY 23% LARGER THAN PREVIOUS BROTHER SCREENS



  ZOOM AND ADJUSTMENT FEATURES
  View your creations in crisp, vivid color and watch them become larger than life with the zoom function of up to 400% within My Design Center and up to 200% in other modes. Easily adjust your design by rotating in .1mm increments.

  USER INTERFACE
  Larger, more defined crystal clear icons, color navigation, scrolling menu and the ability to view your design properties in preview mode.

  EXPANDABLE LIBRARY OF BUILT-IN TUTORIAL VIDEOS
  Built-in HD tutorials make learning easy! View over 40 tutorial videos directly on the high-definition LCD display, or stream your own creations using the industry standard MP4 format. You can even watch videos or listen to music while the machine is not running.

  56 SQUARE INCHES OF WORKSPACE
  11.25" needle to arm! Our largest needle to arm is a dream for any quilter with the ability to accommodate a rolled king-sized quilt! Enjoy over 56 square inches of workspace.

  38% Larger Embroidery Area that previous Models 9.5" x 14"
  STABILITY PLUS™ FRAME. MAKE YOUR PROJECTS LARGER THAN LIFE WITH OUR LARGEST AND STRONGEST EMBROIDERY YET. With the addition of aluminium, rubber and ribbed corners, our improved embroidery frame offers less slippage for better stitch results

  ACCUTRAC™ EMBROIDERY SYSTEM




  Engineered for superior stitch quality. Bask in the pleasure of even more precise, high quality embroidery with our most advanced AccuTrac™ embroidery system. Created and used in our multi-needle PR-Series, it provides better under arm support, reduces bounce, provides better stitch quality, as well as sophisticated mechanical changes for the smoothest frame control to date.

  Disney is in our DNA
  Select from an awe-inspiring collection of 930+ built-in designs, including
  166 Disney designs.

  Industry First INNOVEYE® 2 TECHNOLOGY IT'S LIKE HAVING A BUILT-IN CAMERA & SCANNER
  This industry-first technology gives you a live and up close view of the needle area for the most precise positioning ever. The ability to scan the entire embroidery area provides endless creative options and helps ensure that all of your projects are perfect.

  SNOWMAN® EMBROIDERY POSITIONING MARKER
  We've enhanced our beloved Snowman® Embroidery Positioning Marker to offer more options for alignment of embroidery designs. Pair with the lnnovEye® 2 Technology to automatically position the needle and design for precise embroidery placement.

  Industry First MY DESIGN CENTER MAKE YOUR PROJECTS AS UNIQUE AS YOU
  The next generation of My Custom Design has been enhanced to integrate our industry-first InnovEye®2 Technology, offering design capabilities at your fingertips, all without a PC. Draw or doodle directly on the LCD display, and watch it spring to life in the large drawing area. Or, use the industry-first scanning frame to scan line art, handwriting or printed clip art and have it transformed into embroidery data. There are so many ways to create a custom personal work of art-and a really fun way to create embroidery!

  Industry First: INTRODUCING OUR SCANIMATION™ SCANNING FRAME AND TECHNOLOGY
  The industry's first scanning frame that works directly on your machine. Using lnnovEye® 2 Technology and our state-of-the-art ScanImation™ Scanning Frame, you can scan drawings and printed clip-art directly into My Design Center.

  DRAW DIRECTLY ON THE LCD DISPLAY
  Use the included stylus to draw directly on the LCD display and see your designs or handwriting instantly spring to life in the large drawing area. No more tablet needed.




  LINE ART SCAN & EMBROIDER
  Use the industry-first lnnovEye® 2 Technology to scan handwriting or line art on the industry-first Scanlmation™ Scanning Frame, and then watch as they are transformed into unique embroidery designs. You can also draw directly on the 10.1" built-in HD LCD display.




  ILLUSTRATION SCAN & EMBROIDER
  Use the industry-first lnnovEye® 2 Technology to scan an image or illustration on the industry-first Scanlmation™ Scanning Frame. Or import a JPEG using the USB port, and watch in amazement as the image is turned into stitch data using just the machine.




  SCAN & STIPPLE
  Accurately stipple anywhere on any project. Simply scan your fabric using InnovEye® 2 Technology and define the stippling area using the stylus directly on the LCD display. Choose your desired stipple pattern and THE Dream Machine does the rest.

  INSIDE & OUTSIDE AUTO STIPPLE
  You can also use the built-in library of shapes and patterns to add interesting detail to any project. You can even combine shapes and select inside or outside stippling to create unique designs.

  CUSTOM DRAW STIPPLING
  Use the industry first ScanImation™ Scanning Frame or draw directly on the LCD display to create your own unique patterns. Now you can get the look of complicated freehand stippling without the use of software or stitch regulation!




  Industry First: MUVIT™ DIGITAL DUAL FEED SYSTEM
  No more puckering! Feeding fabric has never been smoother! Powerfully feed fabric from the top AND bottom, and sew precise, uniform stitches on a range of fabrics from silk to denim.




  COUCHING TECHNIQUE AND MUVIT™ DIGITAL DUAL FEED SYSTEM
  The couching foot with MuVit™ allows you to add cording techniques to your projects.

  SUPER FAST STITCH SPEEDS
  Finish projects with embroidery and sewing speeds up to 1,050 spm. Plus, select decorative stitches now up to 710 spm.

  Industry First: SEW STRAIGHT™ 2 LASER VISION GUIDE
  Sewing straight has never been easier with the built-in laser guide that creates a path to sew on. Now even easier with the brighter laser line for easier viewing on darker fabrics, and a wider range that extends up to 19mm.
  With double the brightness and manual adjustment, you will be able to see this guideline on any fabric you can imagine.




  Industry First: DROPLIGHT™ LED EMBROIDERY POSITIONING MARKER
  Trying to guess where to drop the needle is a nightmare of the past! Use the embroidery foot with LED pointer to easily see your needle drop position - critical for embroidery. You can check the embroidery field easily with the trial key and the LED pointer. Also helpful while using the stitch forward and backward keys. Now with ± 1000 stitches forward or backward.

  V-SONIC™ PEN PAL FOR SEWING & EMBROIDERY
  The V-Sonic™ Pen Pal system uses ultrasonic technology to allow you to control several functions right on your fabric, so you can reduce the need to look away from your project. When sewing, easily make adjustments to needle position, set stitch width and position, select sewing end point, and set laser guide position. When embroidering, easily adjust the design if the fabric has been hooped crooked.

  COLOR SHUFFLING™ 2 FUNCTION FOR EVEN MORE COLOR POSSIBILITIES
  Love a certain color scheme? Not sure how to combine colors? Use the pin graphic function in Random and Gradient modes to ensure your favorite colors are included in your shuffle




  INNVACHROME™ LED THREAD COLOR AND MONITORING SYSTEM
  No more babysitting your machine! Our revolutionary visual status system indicates when a thread color change is needed, what the next color is, as well as thread breakages and alerts. Originally designed for our PR-Series of machines.




  Can Your Machine Do This? My Design Center | THE Brother Dream Machine Feature Showcase. Watch how with My Design Center, creating embroidery designs is as easy as drawing on the LCD screen.


  My Design Center Complete Brochure

• 18” deep X 10” high

• Built in bobbin winder

• Auxiliary hand wheel

• THREAD TRIMMER!

• Semi Dry head technology

• Direct drive servo motor

• Metal gear timed

• Auto tie off feature

• Basting stitch

• And MORE

  Installation Instructions: (.PDF) Set Up Manual For Juki TL2200QVP-S Sit Down Quilting Table. Please call us to speak to John, our tech, if you have any questions. It's easier than it looks on paper, and changes have been made to make it easier.

  Information Below Applies Only to TL2200QVP and J-350 Frame Models, not to TL2200QVP-S or J-350QVP Sit Down Models.
  Handles are not included and not needed for free motion quilting where you are moving the fabric under the needle.

  "Just took the Long Arm quilting class at Allbrands and it was awesome. The teacher Kay was so great and full of knowledge. Once you take the class you can rent the machine by the hour to quilt your own quilts!! Sign up, you won't regret it!!" Lisa M

  Direct drive motor with metal gears without any belts makes the machine more responsive and quieter. Specifically the motor is built into the head on the main shaft and the lower shaft is turned by a gear, there is no belt noise.

  The Juki TL-2200QVP Quilt Virtuoso Pro Long Arm Quilter is the newest Long Arm Quilting Machine on the market and from Juki in Japan and the only one on the market with top and bobbin thread trimmers.

  It has 18x10" or 180 square inches of arm space, compared to 118" for Tin Lizzie 18x6", 144" for Handiquilter Avante 18x8", and 144" for Tin Lizzie 24x6" heads. That's 25% more arm space more than 18x8 or 24x6 arms.

  The touch screen panel has many options. Automatic stitch regulation or manual speed control, up to 16 spi stitches per inch on stitch regulation. Needle programmed to always stops up or always stop down, automatic thread trimming or manual command, etc.


• 18.25" x 10.25" oversize arm space to right of needle is the largest workspace of any 18" longarm on the market. (55% more workspace than Tin Lizzie 18x6" Arm. 25% more than HandiQuilter Avanti).

• Side Mount Hand Wheel eliminates the need reach around to the back of machine for main hand wheel.

• Independent M bobbin winding system allows winding bobbins while sewing, or when not sewing.

• Front or back operation of the machine from front or back of quilting frame. Free motion from the front and pattern motion from the back with laser stylus included and optional quilting design templates or paper patterns on the table.

• Grace All Metal 10 foot 120" frame a $3000 Value (expandable to 12 foot 144" frame with optional extension kit)

• Stitch Regulator with X and Y encoders for the machine and platform which comes with machine.

• Cruise Control Speed Settings as a % of 2200SPM maximum.

• 6-16 Stitches Per Inch Settings for Stitch Length using Stitch Regulator

• Baste to 3SPI Stitches Per Inch (1/2" 1" and 1.5"),

• Presser Foot Adjustable Height for Fabric and Batting Thicknesses, 0-4mm with Slotted Presser Foot Height Adjustment

• 0.5mm Recommended Distance from Bottom of Foot to Needle Plate when Foot and Needle are in lowest position. Adjustable for quilt thickness to prevent fabric from flagging (riding up and down on needle.)

• 1/4" Tall, 1/2" Diameter All Metal Presser Foot for Rulers and Visibility.

• Tack or Stay Stitch to make three stitches in place, and stop with needle up or down.

• Needle Up or Down Settings will always stop with needle in fabric, or needle out of fabric

• Needle Eye Guard to be installed at time of machine set up.

• Presser Foot Lever to be installed at time of machine set up.

• Two spool thread stand to be installed at time of machine set up.

• Automatic or Manual Activation of both Top and Bottom Thread Trimming at the same time, the only quilting machine on the market with these features.

• Super Bright LED No-heat lights above needle (4) and on both left and right handles (3 each).

• Machine Bed Size: 18.25x10.25" (187 square inches) between needle and neck of machine

• Speed: 2200 SPM Stitches Per Minute Maximum Speed Settings. Highest in Manual Free Motion Mode

• Machine Head Weight 26Kg or 57 Pounds

• Compatible with $5000 Grace Quilt Motion, Grace $2000 Creative Touch Pad Upgrade, Robotic Quilting Systems.

• Sets up in 10' or 120" King or 5' or 60" Crib widths.

• Batting Rail Included

• Quick Release system for Rails, including those with rachets or tensioners.

• Adjustable quilt frame leg Height up to 7" difference

• Optional 2ft Extension to do 7" or 84" and 12' or 144"


  ---

  Unique Design
  The Quilt Virtuoso Pro has a slim sleek and sturdy design, unlike any Long Arm Quilting Machines to date!

  Extra Large Throat Space
  Discover the impressive 18 inches of horizontal throat space between the arm of the machine and the needle. Even more impressive is the 10 inch height, unlike most long arm quilting machines which only provide 6 to 8 inches of height

  Bright LED Lights
  10 Ultra Bright LED Light Bulbs over the needle and pattern area illuminate your workspace like never before, making it easy to see detailed work, while simultaneously reducing strain on your eyes.

  Built-in Scissors
  Convenient automatic scissors simultaneously trims the top and bottom thread. No other Long Arm Quilting Machine has this feature!

  Ergonomic Handles
  The TL2200 QVP comes equipped with ergonomic handles for ease and comfort while quilting. The ergonomic handles swivel from vertical into horizontal micro handles for precise close up detailed work! No need for extra set of micro handles.

  Needle Up/Down
  Easily move the needle up or down with the included Needle Up/Down Button. If the machine is off you can use the easy to reach hand wheel on the front of the machine allowing you to raise and lower the needle without having to turn on the machine or reach all the way around to the wheel on the back of the machine.

  Independent bobbin winder/motor
  The built-in bobbin winder has its own motor independent of the machine, so you can wind bobbins while you continue to quilt or while the machine is idle.

  Ultra Glide Tracking System
  Eight Ball bearing wheels hug the track of the frame in a V shape, ensuring smooth even quilting at all times.Machine will not "jump" off the rails.

  Take-up Bar
  The take-up bar allows you to roll up your quilt all the way without making any adjustments to the frame, unlike most other quilting machine frames where you have to adjust the rails up and down as the quilt fills the machine throat. Idler or dead bar below take up bar holds the fabric down to the bed to prevent flagging of fabric which causes skipped stitches.

  Made in Japan
  The TL2200QVP is made and assembled entirely in Juki's leading industrial manufacturing plant in Japan - not in China or Taiwan. It used technology developed for Juki's line of industrial sewing machines which have been proven benchmarks for decades of production and use. The All Metal Frame is made by Grace in Salt Lake City, Utah.

  Leader in sewing and quilting
  Juki is the Leading manufacturer of industrial sewing machines worldwide. Juki has taken this industrial knowledge and experience and put it into this long arm quilting machine for home use. The result is a unique heavy-duty high quality long arm quilting machine that all quilters are sure to love. 400W Motor is the strongest in the industry.

  2,200 SPM Stitches Per Minute Maximum Sewing Speed
  Obtain faster results! The TL-2200QVP offers professional speed so you can complete projects in record time. You can quilt faster on a Juki QVP than any other quilting machine made for the home market.

  Stitch Control - Perfect Tension Balanced Stitches
  The stitch balance control allows you to deliver more consistent stitching according to your needs for a perfect finish on your quilt. Pretension knob guarantees correct length of thread tail after thread trimmer is activated.

  Built-in Stitch Regulator
  Start, stop, speed up and slow down the motor of the quilter delivering the exact amount of stitches per inch that you have set in with the built-in stitch regulator on the TL-2200QVP Quilter. 10-12 SPI Stitches per Inch Recommended.

  Four Stitching Modes
  Work on your project the way you see fit! With three different stitch modes (Cruise doesn't stop stitching, Precise stops stitching when you stop, Manual Free Motion up to 2200SPM, and Baste for .5 to 1.5" stitch length) you can set up your stitching preferences and obtain the results you are looking for without added effort.

  Large 3.5" Color Touch Screen LCD Display
  Maintain absolute control with a top of the line Color LCD touch panel display where you can manage the stitch regulator, light settings, needle speed, stitch length, sound, screen brightness and all you need to complete your masterpiece.

  Automatic Thread Trimmer
  The machine is equipped with an automatic thread trimmer device that simultaneously trims the needle and bobbin threads to 1/4" at the sewing end by lightly pressing the push-button. It uses the same industrial thread trimming mechanism that was invented by Juki for their high speed straight stitch machines starting with the DDL555 to DDL8700 and has been in proven use for decades.

  Adjustable Front and Optional Rear Handles
  Added comfort and maneuverability with the adjustable front and optional rear handles that will give you complete control over your project from any position around the machine. Front handles are used for free motion quilting. Read handles can be used for following patterns with laser stylus included.

  Handle Bar Controls
  Start/Stop with Right Handle Button - Needle Up/Down with Left Handle Button. Controls at the reach of your finger tips.

  Compatible with ¼ Inch Thick Rulers because the presser foot ring is 1/4" tall

  All Metal Solid Steel Heavy Duty Virtuoso Frame by Grace Frame

  Internal Motor
  Internal motor provides a quiet smooth operation, without any belt/noise.

  Dry Head System
  Thanks to the advanced dry-head technology (4 sealed permanent lubrication metal bearings on main shaft and 5 silicone impregnated and brass bushings throughout rest of machine) no lubrication is required except for the rotary hook section before each quilting project. This eliminates oil stains on the sewing product.

  Quick Response Direct Drive Motor - No Drift and No Belt to Slip
  For quiet and smooth operation.

  Easy Access Auxiliary Hand Wheel
  Obtain faster results! The TL-2200QVP offers professional speed so you can complete projects in record time.


  ---


  You can register your Juki machine purchase online with our new Registration page. Click here to Register.

  Juki TL2200QVP Product Brochure(.PDF)

  Juki TL2200QVP Longarm Sewing Machine Instruction Manual(.PDF)

  Juki TL-2200QVP Parts and Service Instruction Manual(.PDF)

  Juki TL2200QVP Instruction for Presser Foot Lift Installation(.PDF)



  ---


  Description & Specifications
  Sewing speed: Max. 2,200SPM Stitches Per Minuet
  Needle bar stroke: 35mm
  Lift of presser foot: 5.5mm
  Needle: GB, Organ or Schmetz 134R and equivalents.
  Lubricating oil: New Defrix Oil No.1, or any clear sewing machine oil.
  Dimensions of sewing machine: 22.2W x 46.0H x 73.0L (cm)
  Weight of sewing machine: 26 kg. 57 Pounds
  Rated power supply / Power consumption: 120V/140W 60Hz

  Click here to access the Juki warranty registration form

  UPCs:
  Box 1 of 4: 636343171444
  Box 2 of 4: 636343171468
  Box 3 of 4: 636343171475
  Box 4 of 4: 636343171482
  Juki Tech Brian Debrick and National Educator Karen Pharr train AllBrands staff on QVP April 19, 2013







  Attaching fabric to a Grace Quilting Frame Video:


  From Juki Brand Ambassador Nicole Moore:
  "I found great success with my JUKI industrial, so it was an easy decision to purchase additional JUKI machines like the JUKI TL-2010Q straight stitch sewing machine. This is hands-down my favorite machine to sew on! I can easily piece my quilts, make most bags and even do some free motion quilting. It sews like a dream! And because I love free motion quilting, I added a JUKI J-350QVP as well. I occasionally quilt other people’s quilts, but because my long arm is currently on a table (and not a frame) I mostly just quilt my quilts with my J-350QVP. One of my business goals is to transition my long arm sit down to a frame and add the automation package. Both my kids are still in the house so until they fly the coop, I don’t have the real estate in my home for a longarm business right now. I’m also learning more about making garments so it only makes sense that I have a JUKI serger and cover stitch combo, MO-735. I bought these as gifts for my Mom and love to use them when I visit her. My mom still loves to teach me new things since sewing garments is something that I am still learning more about."

  There are several ways to stay in touch with Nicole. You can find her on Instagram every day. Subscribe to her YouTube Channel and sign up for her Weekly Newsletter. Nicole even has a Facebook Page and TikTok Channel. If you need help or are interested in starting a Creative Business – be sure to visit the Creative Day Job website!

• Quiltmotion Software Features

• Design and edit full quilt layouts, borders, pantographs and blocks

• Trace patterns from pictures or create your own

• Pattern library with 200 quilt-ready patterns

• Import different file types from other programs

• Accurate pattern placement records

• On-screen preview of patterns before quilting

• Switching between computer-guided and free-hand quilting

• Record and save free-hand quilted patterns

• Convenient control via LCD display on the sewing machine

• Hardware and motor plate necessary for controlling machine

  How to Place Patterns:
  Quiltmotion Software allows you to use many pattern placement techniques. Once you have placed a pattern in a block on the main screen in QuiltCAD, selected the stitch option and set your preferences, you are ready to move to the remote display.

  You will need to set your quiltable area on the LCD display to prevent the carriage from moving beyond the edges of the quilt or beyond the reach of the machine’s throat. This is only required the first time that you place a pattern after launching the program. It is also recommended that you reset the quiltable area after you have advanced your quilt about four times to set an accurate area. The prompts at the bottom of the display will guide you through the process.

  The remote display features buttons on the left and right sides for performing various functions. For example, pressing the “Quilt Motion” button displays placement and fill methods. You use the buttons to specify the various options required for your quilting in a user-friendly manner. You can set many things on the display, including the required stitch speed.

  The margin offset feature allows you to offset your pattern from the border of the block in eighth inch increments. This enables you to fit your pattern with a consistent margin all around the block. You can set the margin either at the computer or on the LCD display. You may also stretch or tilt your pattern to fit your block.

  Quiltmotion Software is compatible with Windows 7 and newer operating systems and has the same features as Brother Dream Motion Pro software and hardware below which is also made by Grace

  Quilter’s Creative Touch 4 is the top-of-the-line automated quilting system. The ability to create, design, and quilt with absolute precision are right at your fingertips.

  Based on our original software, QCT4 is now more powerful, yet easier to use than ever before.Quilter’s Creative Touch Software Features

  Imagine an affordable, fully-featured computer automated quilting system in your own home! A motor plate attached to the machine carriage accurately controls the motion of the sewing machine for precise pattern stitching.

  Let QCT4 do all the stitching for you and you'll get the perfect pattern, stitched exactly how you imagined it, every time! The software can be installed on any tablet with Windows 7, 8, or 10, giving you the freedom to design your own patterns or layout your quilt anywhere you want.

  Quilting a pattern with Quilter’s Creative touch can be as easy as:

  Select from an extensive library of over 200 patterns or design your own.
  Place a sewing area on your quilt with your machine. The screen will show your pattern in relation to your placement and how it will really appear as sewn!
  Quilter’s Creative Touch controls your sewing machine to accurately stitch your patterns, exactly as you placed them!
  Features
  Computer automated quilting
  Easy pattern sizing, rotating, & flipping
  Continuous rows with Panto Stacker™
  Advanced Pattern Placements
  Marking Tool (Capture points on fabric and see them on the screen)
  Batch import & convert other file types
  Export pattern to a different file type
  Print any pattern or pantograph
  Create & edit patterns with PatternCAD™
  Design entire quilt layouts with QuiltCAD™
  Record free-motion quilting as patterns
  Create & save templates for future use
  Borders and Corners™
  Virtual Longarm™
  Font Stitcher™
  Make & save corner patterns
  Quilter's Creative Touch 4 features a newly improved interface that's more powerful and easier to use. The whole software has been made to work with touch-screen tablets, offering the freedom to use it wherever you go, and have all the functionality right at the sewing machine where you need it most.

  Set your pattern on your quilt exactly how you want before having the machine quilt it for you. There are 7 different placement methods to choose from, so no matter the type or shape of your pattern, you’ll be able to place it just right!

  As you set the pattern area with your machine, the screen shows exactly how it will appear when sewn!











  Installing the QCT 5 Quilting Automation Software and Hardware



  Advance to Nest Your Quilt to the Next Zone Using Grace QCT5 Pro Software.


• B9 Hook system


• 1000spm Maximum sewing speed


• 10 inches/254mm Length of freearm to the right of the needle


• Color touchscreen


• 30 LED sewing lights


• 9mm Maximum stitch width


• 6mm Maximum stitch length


• 11 Needle positions


• Sewing in each needle position


• 2 Spool holders


• Semi-automatic needle threader


• Adjustable presser foot pressure


• Automatic thread cutter


• 3 Manual thread cutters


• BERNINA Dual Feed


• Memory (short-term/altered stitches)


• Memory (long-term/altered stitches)


• Create and save stitch combinations


• BSR functionality (straight stitch and zigzag)


• Start/stop button (stitching without foot control)


• Slide speed control


• Upper thread indicator


• Lower thread indicator


• USB interface for PC connection


• USB interface for USB data stick


• Multi-function knobs


• Changing stitch settings while sewing


• BERNINA foot control with kick-back function


• Needle stop up/down


• Bobbin winding while sewing/embroidering


• On-screen help


• Sewing tutorial


• Creative consultant


• Personal program


• History function (most-recently-used stitch patterns)


• Setup program


• Eco mode

Sewing and Quilting

• Directional sewing 360°


• Sideways motion feed


• Pattern start/end function


• Connecting stitches


• Elongation


• Security function program


• 1,306 Number of stitch patterns (incl. alphabet) total


• 32 Utility stitches total


• 15 Buttonholes (incl. eyelet)


• Automatic buttonhole-length measuring system


• Automatic buttonhole


• Manual multi-step buttonhole


• Button sew-on program


• 3 Darning programs


• 460 Decorative stitches total


• 91 Decorative sideways motion stitches


• 33 Quilting stitches total


• 28 Cross-stitch programs


• 52 Tapering/skyline stitches


• 8 Sewing alphabets

• Included wide table for larger projects

• 5" x 11.25" spacious workspace for large quilts

• 10” LED lighting

  Main Features:

• 561 sewing stitches (531 built-in, 30 on CD), 14 one-step auto-size buttonhole styles, 3 sewing fonts, and 5 sewing lettering fonts

• 5'' x 11.25'' Spacious workspace for large quilts

• Large 3.6'' x 6.0'' LCD touch screen display

• Sew Straight Laser Vision Guide

• V-Sonic Pen Pal for sewing

• MuVit Digital Dual Feed

• Automatic Height Adjuster (AHA) feature

• Pivot function

• 10" LED lighting

• Lockstitch key

• Included wide table for larger projects

• Wide range of included accessories

• Quilters Bundle Included


• New convenient larger touch-screen with more menus

• New user-friendly features and simplified menus

• More powerful motor that is smoother running

• Faster speed and enhanced stitch quality

  The Grace Qnique 15 Pro has a powerful motor capable of quilting over 2000 stitches per minute and the needle area is illuminated with bright LED lights so you can clearly see your quilt.

  The new full-color touch screen has a simplified menu system so you can easily select your stitch length, control whether the needle ends in the up or down position, and change the handlebar controls from right to left handed.

  Includes 1800SPM, 4 V-Track Rollers, Stitch Regulation, Encoders, Front Handles, OLED Panel, M Bobbins and Needles.

  Qnique 15 Pro Quilting Machine Video


  The Grace Qnique 15 Pro has a powerful motor capable of quilting over 2000 stitches per minute and the needle area is illuminated with bright LED lights so you can clearly see your quilt.

  The new full-color touch screen has a simplified menu system so you can easily select your stitch length, control whether the needle ends in the up or down position, and change the handlebar controls from right to left handed.

  Two spool pins are located on the back of the machine along with a built-in bobbin winder so you can quickly wind the large M sized bobbins and get back to quilting.

  The Grace Company set out to make the perfect mid–arm quilting machine for the quilting enthusiast. All of the high–end long–arm features that quilters were looking for were carefully crafted into a truly affordable quilting machine.

  "I purchased a qnique mid arm first , I’ve never used or seen one before this , I was really impressed with how fast it arrived , I set it up with the frame by myself , it went together easily, (I am 81 yrs old ) I learned to quilt on it fast , I like it so much I decided to get the rear handles , too much fun , and easy to use , thank you, Ray M, Alvaton KY"

  New to quilting machine reviews, the top of the line quilting machine is the Grace Company's Qnique Quilter quilting machine. With this machine being the most economical model out there and the best performance for the buck, this machine is awesome. The company that makes this machine, The Grace Company, has been in business for 25 years and leads the industry in quilting machines and accessories. This machine takes the features of the the long-arm machine and combines it with the size and price of a mid-arm quilting machine. The Grace Company's Qnique quilting machine has state of the art sewing technology along with a high grade aluminum body that has everything you need at the touch of a button. It has been built to make even the most difficult of quilts easy to make whether you are an experienced quilter or are just getting started. It doesn’t get any better or easier than this. This state of the are machine makes the very best of quilts out there.

  State of the Art
  This machine has a state-of-the-art bobbin system with a bobbin winder that is built into the machine. It has high speed that works automatically as you need it. When you need to refill the bobbin, you just use one of the threads from the tower and it winds itself. It turns on automatically and turns itself off when you are done. This machine also has an easy-access bobbin case that just pops open and makes it easy when you need to change or adjust your bobbin. The bobbin is larger than the usual size on most machines, so that you can quilt longer without stopping.

  You now have more control of your work space with six buttons on the handle to work with, to make things faster and easier. This machine also comes with its own regulation of stitches that is built into the machine as part of how it runs and has a hand dual thread tensioner to help when quilting. It has 6 LED lights that light up your needle area for easy visualization of your work space and the stitching that you are doing. It has two thread holders with the fastest sewing speed possible of 1800 stitches per minute.

  Biggest and Best Quilts
  This machine is made to make the biggest and thickest of quilts and makes sewing faster than any other machine. The Grace Qnique sews seven to fifteen stitches per inch when stitching. It even has three different stitch regulators to make sure your stitches are even and consistent. You also have a manual speed control to be able to control the speed of the stitching yourself. If you get to stitching too quickly, there is a warning that tells you that you are stitching too fast for what you are stitching. This quilting machine comes with large throat space that has the most room for the largest and highest quilting material for stitching on the market today. This makes quilting so much fun to do at home and it couldn't be easier.

  Qnique Laser Stylus
  Did you know that the Qnique Laser Stylus accessory can be easily attached to the machine to help you trace patterns or pictures while you are quilting on a quilting frame? You have the choice of attaching the laser to the front or rear handles, or even to the bottom of the machine, between the wheels.

  The easiest way to trace a pattern when you are quilting is to use the Qnique Laser Stylus. Using this accessory, you can just put the pattern you wish to trace to the side and trace it with the laser as you quilt. The Laser stylus plugs right into the Qnique’s accessory port for power, so you do not have to buy any batteries. The laser is designed to be versatile and can work while attached to the front or rear handles. It will also work near the bottom of the quilting machine. You can angle the laser in any direction, the way you want it to work.

  Grace Qnique Quilting Machine
  The Grace Qnique Quilting Machine is made with quality and performance and cost in mind. These machines are industrial strength and have industrial strength performance. They make the making of quilts so easy, even a beginner could get started right away. This really is the best quilting machine out there for the money. The Grace Qnique Machine includes several accessories such as the lubricating oil to keep it running smoothly and correctly, quilting needles to sew with, and bobbins to use to help make those gorgeous quilts. Quilters are a great group of quilters who recommend this machine with an 89 percent rating.

  There are also a lot of blogs, and websites like (www.quiltingindustry.com) where you can get information on the newest accessories, quilting clubs, news, and see what all the other quilters are making. You will find out about their newest tricks, the newest on material, what is selling, and reviews, tutorials, classes and all about when the next quilting shows are.

  This machine only uses 300 watts of maximum power and its LCD light automatically shuts off after 15 minutes if not in use. It even has four plugins; for use of other quilting machine accessories that you might want to use. The Grace Qnique works easily with any frames that you might be already using. There are also many frames designed that are available to work specifically with this machine such as the Q Zone Quilting Frame and the Qnique 15PRO. The Q Zone Hoop Frame is a king size frame which handle the larger quilts.
  The extended length and height of the work area on the Qnique quilting machine gives you the freedom to quilt larger patterns or blocks. The Qnique features a 15 inch throat space from the needle to the back of the work area.

  With stitch regulation, increased stitch speed, extended throat space, advanced control settings, and so much more; the Q'nique long arm quilting machine is truly the most economical long arm quilting machine on the market!

  Features:

• The 15 inch throat lets you sew larger patterns and blocks

• Larger throat space for a more convenient, less cluttered work area

• Comfort Grip Handles

• Convenient quick-access buttons for easy control of sewing functions

• Every part has been fine crafted and tuned, to give up to 1,800 stitches per minute, so you can blast through your quilts faster than ever

• Stitch regulation keeps your stitch length consistent, even as you speed up and slow down

• The OLED screen displays an easy to navigate menu, which includes four different sewing modes

• Included Motorized Bobbin Winder can wind a bobbin without running the machine

• A bright OLED screen displays sewing settings

• Large class M bobbin for longer quilting times without needing to change your bobbin

• Easy-access bobbin for simplified changing

• Dual-cone thread towers

• Multiple accessory ports let you attach convenient sewing machine add-ons

• Illuminate your work area with the integrated LED work lights

  Quilting Controls:
  The Q'nique long arm quilting machine was designed to be as user friendly as possible. All of the main controls and settings can be adjusted and controlled from the handles and seen on the full-color display on the front of the machine.

  Needle Position:
  There is no need to reach around the machine to adjust the hand-wheel, with a push of a button you can raise or lower the needle. By holding the button you can even set a "needle stop position" that will return the needle to that spot when you stop quilting.

  Stitching Speed:
  The buttons on the handle bars allow you to adjust the speed of your stitching faster or slower. These same buttons control your stitch length when in stitch regulation mode. The regulation will adjust the speed for a consistent stitch after you set the stitches per inch.

  LCD Display:
  Your most important settings and quilt functions can be found right on the front LCD display. This means quick access to needle position, stitching mode, stitch speed, or stitch length.

  Stitch Regulation:
  With four different stitch modes, the Q'nique is just as powerful as a high end long arm quilting machine but at a fraction of the cost.

  The stitch regulation knows when you speed up and slow down, and will adjust the speed of the stitch according to your movements for a clean and consistent stitch everytime! The stitch regulation can handle the full power of the Q'nique, stitching 1800 stitches per minute!

  Stitching Modes:
  In Precise Mode you control the "stitch per inch" setting for consistently sized stitches. Stitch regulation adjusts the stitch speed as you quilt faster or slower. Precise Mode stops stitching when you stop moving the machine.

  In "Cruise" mode, you set the SPI as well as a minimum stitch speed. Regulation adjusts to keep stitches consistent, but whenever you stop or slow your movements, the machine will continue to stitch at the minimum set speed.

  Baste mode is perfect for when you want to do some long basting stitches on the edges of your quilt. You can set the the basting stitch length to short, medium or long.

  Manual mode lets you control the stitch speed of the quilting machine. With the touch of a button on the handle bars, you can increase or decrease the constant speed. This is great for detailed or intricate stitching.

  Basic Machine Includes:

• Front handles

• Electronic display

• Encoders

• Power cable

• 3 Qty M-Class bobbins

• 10 Qty sewing needles

• Sewing machine oil

• Allen wrenches, screw drivers, lint brush

  View Qnique Warranty Information Here


• 351 stitch patterns and 4 fonts

• 12 standard feet

• Throat space: 12" x 4.7"

• Workspace dimension: 22.4" x 13.5"

• Bright, color settings touch panel

• One-button drop feed for free motion quilting

• Automatic thread trimming by foot control or push of button

• Easy replacement of straight stitch plate and feed dog

• Equipped with Juki dual feed system

• Needle up/down button

• Advanced automatic needle threader

• 6 bright LED lights

• Bobbin thread counter

  Click here to access the Juki warranty registration form

• 561 sewing stitches (531 built-in, 30 on CD), 14 one-step auto-size buttonhole styles, and 5 sewing fonts

• MuVit Digital Dual Feed

• Large 3.6'' x 6.0'' Color LCD touch screen display

• Automatic Height Adjuster (AHA) feature

• 10” LED lighting

• Improved sewing with longer feed dogs and J foot

• Pivot function

• Lockstitch key

• 5'' x 11.25'' Spacious workspace for large quilts

• Built-in USB port

• Included wide table for larger projects

• Wide range of included accessories

• Quilters Bundle Included

• Included wide table for larger projects

• 5" x 11.25" spacious workspace for large quilts

• 10” LED lighting

  Main Features:

• 561 sewing stitches (531 built-in, 30 on CD), 14 one-step auto-size buttonhole styles, 3 sewing fonts, and 5 sewing lettering fonts

• 5'' x 11.25'' Spacious workspace for large quilts

• Large 3.6'' x 6.0'' LCD touch screen display

• Sew Straight Laser Vision Guide

• V-Sonic Pen Pal for sewing

• MuVit Digital Dual Feed

• Automatic Height Adjuster (AHA) feature

• Pivot function

• 10" LED lighting

• Lockstitch key

• Included wide table for larger projects

• Wide range of included accessories

• Quilters Bundle Included

• Exclusive Bag Set Included - $299.99 Value

• EleVen Inch Chassis: All of the V series feature the largest needle to arm distance ever from Brother at 11.25"! At 56 square inches, this is the Largest Workspace Ever from Brother (over 10% more than previous models). Video


• Vibrant 10" Runway® Lighting: 50% brighter than previous models. Video


• V-sonic^TM Pen Pal: *Industry First! Set Stitch Width and Length, Change Needle Positions, select sewing end point, and set laser guide position without taking your eyes off of your project. Simply, touch and sew! Video


• Sew Straight^TM Laser Vision Guide: *Industry First! Use the built-in laser to assist in create a path to straight sewing in this "seeing is believing"feature. Video


• Velocity up to 1050 Stitches per Minute: The fastest Brother Series ever!


• MuVit^TM Digital Dual Feed Top Roller Belt Feed System: *Industry First Replaces the traditional walking foot. This included digitally-controlled, direct motor-driven accessory foot was designed for difficult projects which require special handling- so you can rest assure that your ability to move it smoothly is just a touch away. Video


• SeVen Inch LCD Touch Screen Display: Provides the latest LED, lack-lit technology for clear, bright, efficient viewing of all onscreen operations. Video


• Vast Wide Table Included: Fits a whole Rolled up King Sized Quilt


• *Optional Versatile Multifunction Foot Controller: *Industry First Adjustable and programmable bi-pedal foot controller offers hands-free control of 3 vital quilting and sewing functions: Thread Trim, Reverse Stitch, & Needle Up and Down. Video (available for additional purchase)


• 561 sewing stitches (531 built-in, 30 on CD)

• 14 1-step buttonhole styles

• 3 sewing fonts, 1 Cyrillic font and 1 Japanese font

• Sew Straight™ Laser Vision Guide

• V-Sonic™ Pen Pal for sewing

• MuVit™ Digital Dual Feed

• Our largest workspace ever - 5'' x 11.25''

• Large 3.6'' x 6.0'' LCD touch screen display

• Automatic Height Adjuster™ AHA® feature

• Pivot function

• Lockstitch key

• Included wide table for larger projects

• Speed: up to 1050 stitches per minute

• 13 Bobbin Works Designs with Included Bobbin Case

  Click HERE for machine quilter Paula Reid's blog on Brother V Series Sew Straight Laser Guide

  Product Brochure for All Brother V Series Machines 2014(.PDF)

• Robotics Animation

• Precision Sewing and Pattern Placement

• Two-row Pantograph design layout

• Exclusive feature: Zone-to-zone fabric management to transition patterns seamlessly across your quilt.

  BEGINNINGS EDITON:
  Quilter's Creative Touch 5 Beginnings is the budget–friendly way to get into automated quilting. It offers all of the essential features of the full version to get you started in steps as simple as select, place, and sew.

  The Beginnings tier is the perfect introduction to computer automated quilting. Select patterns from the included library, and easily place them on your quilt for sewing. If you ever decide to take the next step and start designing your own patterns, an upgrade option to the fully featured QCT5 PRO tier may still be available.

  See Brother Video on SAQCDM and SAQCDMPRO PRO versions






  FEATURE COMPARISON QCT5 BEGINNINGS: / QCT5 PRO
  Computer Automated Quilting Yes / Yes
  Library Of Over 200 Patterns Yes / Yes
  Pattern Sizing, Rotating, & Flipping Yes / Yes
  Continuous Rows With PantoStacker Yes - Limited / Yes - Regular
  Open Patterns Of Different File Types Yes / Yes
  Advanced Pattern Placements Options No / Yes
  Marking Tool* No Yes
  Batch Import Multiple Other File Types No / Yes
  Export Patterns To Different File Types No / Yes
  Print Pattern Or Pantograph No / Yes
  Create And Edit Patterns With PatternCAD No / Yes
  Design Entire Quilt Layouts With QuiltCAD No / Yes
  Record Free-Motion Quilting As Patterns No / Yes

  Looking to get computerized quilting at an even more affordable price point?
  QCT5 Beginnings is a budget-friendly automated system that offers all of the essential features of computerized quilting. Just like the full version of Quilter’s Creative Touch, the Beginnings tier lets you create your masterpieces in steps as simple as select, place, and sew.

  The Beginnings tier is the perfect introduction to computer automated quilting. Select patterns from the included library, and easily place them on your quilt for sewing. I


Ruler Foot: You can switch to free-motion sewing or quilting. A transparent ruler template compatible presser foot is included. It provides even more quilting possibilities.

Color Touch Panel: Allows you to change settings such as thread tension, presser foot pressure, pivot function, drop feed system, and automatic thread trimming with one touch. Additionally, you may select, combine, and save your favorite stitches on an easy-to-use, full-screen list of stitches!
Easy to Use Digital Tension: Needle thread tension can easily be set on the touch panel screen and stored in memory. Recall your favorite tension settings with the touch of a button!
Large Illuminated Workspace: Dual LED lighting to illuminate 22.4" x 13.6" workspace with an addition of 2 lights over the needle for extra light. Level of brightness can be adjusted.
Presser Foot Pivot Function: Sew corners or pivot with ease, when you stop sewing, the needle stops in the down position and presser foot automatically lifts to allow for fabric movements.
Free Motion: Lower the feed dogs with the touch of a button for smooth and effortless free-motion sewing.
Interchangeable Straight Stitch Feed System: Effortlessly switch to perfect straight stitch sewing with revolutionary interchangeable Feed System. Create perfect stitches from beginning to end. No pulling, bunching, or pushing fabrics into the needle opening. Smooth handling for perfect piecing, close edges, curves, layers, and more. Perfection!
Buttonhole Sensor System: With Juki’s combination of industrial and modern technology, this system automatically measures and evenly sews on both the right and left sides to create beautiful buttonholes.
Equipped with JUKI Smart Feed: Engage the JUKI Smart Feed dual feed function to move the top layer of your fabric in sync with the lower layer. Adjust the feed amount by 0.2mm for beautiful stitching without worry of shifting layered fabrics.
Automatic Thread Trimming: With the push of a button or the click of a heel, you can now automatically trim thread.
Foot Lift Function

The Kirei HZL-NX7 is also equipped with a micro-lifter presser foot function. This function reduces uneven sewing on quilts and velvets.

When the presser foot is raised, the feed dogs automatically lower for easy placement of fabrics.

Users can also sew appliques with the pivot function.

• 351 stitch patterns and 4 fonts

• 12 standard feet

• Throat space: 12" x 4.7"

• Workspace dimension: 22.4" x 13.5"

• Bright, color settings touch panel

• One-button drop feed for free motion quilting

• Automatic thread trimming by foot control or push of button

• Easy replacement of straight stitch plate and feed dog

• Equipped with JUKI dual feed system

• Needle up/down button

• Advanced automatic needle threader

• 6 bright LED lights

• Bobbin thread counter

  Click here to access the Juki warranty registration form

• Since the machine comes with a needle-thread take-up mechanism as well as a looper thread take-up mechanism, to offer upgraded responsiveness from light- to heavy-weight materials with a lower applied tension, it achieves well-tensed soft-feeling seams that flexibly correspond to the elasticity of the material at the maximum sewing speed of 8,000rpm

• The newly adopted upper and lower needle bar bushings of the needle bar mechanism improve both the durability and reliability of the needle bar unit. The machine comes standard with a cartridge type oil filter and cooling fan for further improved reliability and durability.

• Gauges and devices you have used with your existing JUKI machines are also interchangeable with no additional machining. This eliminates both the waste of resources and unwanted extra costs.

• See Optional Juki MO6704-150 1.6mm Dedicated Rolled Hem Merrow Stitch Edge, Industrial Overlock 3-Thread Serger MO-6704-150, 4:1 Differential Feed, Power Stand 7000SPM, 100 Needles. This model available to be set up as exclusive and dedicated narrow rolled hem machine, Juki MO6704-150.

  The machine ensures both beautiful and upgraded seam quality at higher speeds.
  Since the machine comes with a needle-thread take-up mechanism as well as a looper thread take-up mechanism, to offer
  upgraded responsiveness from light- to heavy-weight materials with a lower applied tension, it achieves well-tensed soft feeling
  seams that flexibly correspond to the elasticity of the material at the maximum sewing speed of 8,000 to 8,500sti/min.
  To offer improved sewing capabilities as well as to prevent stitching misshapes, the machine is equipped as standard with
  the needle thread heat remover and needle cooler.

  The machine has been developed with the intention of providing an extended service life.
  The machine incorporates various mechanisms as standard, such as a differential-feed micro-adjustment mechanism and
  an external adjustment mechanism for adjusting the feed dog inclination as well as increasing the differential feed ratio,
  which can be easily adjusted to finish seams that perfectly match the material to be used. Comfortable operation is all
  but guaranteed, by a wider area around the needle entry, the adoption as standard of a micro-lifter feature that offers
  improved responsiveness to materials and provides the operator with upgraded operability, and by the reduction of
  operating noise and vibration, which has been achieved by designing an optimally balanced machine.

  Further increased reliability.
  The introduction of a shield-structured needle bar
  mechanism and upper and lower needle bar bushings,
  contributes to increased durability and reliability.
  Additionally, the machine incorporates an improved
  feed mechanism and upper looper unit as well as
  coming standard with a cartridge type oil filter and
  cooling fan, thereby ensuring enhanced reliability.

  Devices intended for conventional JUKI machines are also interchangeable.
  Gauges and devices you have used with your existing
  JUKI machines are also interchangeable with no
  additional machining required (excluding the LB
  Series). This eliminates both the waste of resources
  and unwanted extra costs.

• Comes with brackets to attach Table to machine carriage

• Table Accessories sold separately

  Includes Acrylic Platform and Adjustable Height Legs, Custom Fit Portable Freearm Flatbed, for Sewing, Embroidery, Quilting, Serger and BlindStitch Portable Machines.

  Note: Custom Made to Fit Around the Freearm or Flatbed Surface of Your Brand and Model Sewing, Embroidery and Serger Machines. If your sewing machine drop in bobbin (top load) cover does not come straight up and off the needle plate (if it slides toward the operator) or if your bobbin case is underneath to top of the arm (front load), you will need to remove the extension table to replace a bobbin.

  The Sew Steady Ruler Base is built-to-order to fit your specific machine. Please allow 2-5 weeks before shipping and expect a delivery time of 5-7 days. It is well worth the wait!

  If Sew Steady is not familiar with your model of machine, we will contact you for more information. Please note some orders if the dimensions are on file, and a new ruler base must be entered into the manufacturers machines could have a custom order fee. You will be contacted before approval, if you wish to continue in these instances.

  Grace Speed Box
  The Grace Speed Control is a universal foot pedal replacement. Use the dial to set the speed of your sewing machine. It works with many machines on the market so if you switch sewing machines, the Speed Control can too!

  The Grace Speed Control is a universal foot pedal replacement that works with many machines on the market*. lt allows you to have compatibility with multiple machines listed below* Without the Grace Speed Control you would have to use your regular foot controller for start/stop and speed control.

  The Grace Speed Control is compatible with many DC-powered machines that have a single prong foot pedal plug-in. D.C.-powered machines usually have a separate foot pedal plug-in and a power cord plug in.







  Sure Stitch length regulator vs. speed control box: a Quilting Board Discussion Review. In September I purchased a Grace II frame with a Brother 1500s machine. I added the Grace Sure Stitch which is a dual function stitch regulator. You can set the stitch size and the speed adjusts with how fast you move the machine. I can't imagine doing without either.


• Fully automated threading - from spool through needle eye

• Full-color LCD screen

• Updatability via www.elna.com

• On-screen instruction manual

• Hint messages

• Personalized machine function settings

• Adjustable sewing speed up to 850 spm

• Multiple languages

• Automatic thread tension - computer system automatically releases correct thread amount for ultimage stitch performance

• Needle thread and bobbin thread sensors

• Presser foot lever sensor

• Automatic thread cutter key - programmable

• Start/stop key - for embroidery and traditional sewing

• Up/down needle key

• Dual lights - eliminate shadows

• Extra presser foot lift

  Embroidery Features:

• Fully automated bobbin winding - free embroidery bobbin thread spool included

• Extra large embroidery area (24 x 14 cm / 9 ½" x 5 ½")

• Feed dog automatically lowers when embroidery unit is attached

• Multiple hooping – plots points on-screen for alignment of 2 or more large hoopings

• Wide array of built-in designs including Continuous Hoop designs

• On-screen layout, alignment grid turns on and off

• 6 alphabets – resize in 1 mm increments

• Rotate (in 1° increments), mirror image, change size and spacing

• Easy embroidery editing

• 32 permanent memories – up to 120 characters and letters in each

• Temporary embroidery memory restarts where left off

• Power failure function for embroidery

• Hoop detector

  Traditional Sewing Features:

• 320+ stitches, including 12 buttonholes

• Choice heirloom and quilt stitches

• Directional feed patterns – larger than 7 mm with no hoop

• Directional sewing – forward, backward, left, right without pivoting

• 5 alphabets, 7 mm – 25 mm

• Lockstitch – programmable

• Maximum stitch width 7 mm

• Maximum stitch length 5 mm (basting – 20 mm)

• Elongation – satin stitches up to 5 times original length

• Combine stitches from different groups

• 2 color – certain stitches alternate needle and bobbin threads on right side of fabric

• Size – change from small to medium to large

• Mirror image and face to face

• Cascade – 6 choices arrange stitches in steps rather than in a straight line

• Direct editing – edit any stitch within a sequence

• Grid

• 20 permanent memories – up to 120 characters and letters in each

• Strong needle penetration on all fabrics

• Free arm

• Adjustable foot pressure

• Knee lifter

  Storage and Accessories:
  Three convenient storage areas accommodate presser feet, bobbins, needles, screwdriver, quilt guide. lint brush, seam ripper, eyelet punch, scissors, tweezers, fabric marker and more.

  In a world filled with choices when it comes to sewing and embroidery, there's only one choice - the Elna Xquisit II.

• Oversized color touch screen LCD
  Select stitches, embroidery patterns, tutorials by simply touching the screen.


• Automatic Height Adjuster AHA Feature
  Achieve perfectly formed stitches as you sew over varying fabric thicknesses. Perfect for stitching quilts with varying fabric types, appliqués or embellishments.


• Pivoting function
  The presser foot automatically lifts as the needle remains lowered for fast and easy fabric manipulation.


• Built-in stitches and embroidery designs
  314 built-in sewing stitches, 340 embroidery designs, including 129 designs featuring Disney characters, 10 embroidery alphanumeric fonts and 3 sewing alphanumeric fonts.


• Powerful on-screen editing features
  Layout, pattern rotation in 1 degree increments, mirror imaging and scaling for embroidery accuracy. Like what you see? Save it to the memory of the machine for future use.


• Large embroidery field
  Maximum embroidery field of 10" x 6". Includes a medium, large and extra-large hoops.


• Free-motion stitching
  The foot height adjusts for perfect free-motion projects. Included are specialty feet.


• Needle plate measurements
  Easy-to-see numbers and markings, in both inches and centimeters, for accuracy and confidence.


• Built-in dual USB ports
  Connect to your computer for importing and exporting designs or machine upgrades. Use the second port to import and export designs from your USB memory stick



• For Home Sewing Machines

• Patented Dual Sensor Technology

• Perfect for Ruler Work and Free Motion Quilting

• Easy Installation

• Compatible with a Variety of Popular Sewing Machine Brands:

  Brother/Babylock: Part #YAS1000
  Brother 1300
  Brother 1500
  Babylock QCP
  Babylock Accomplish







  ACCUSTITCH Installation Video





  11x23" Extension Table, Knee Lift, 7 Feet including Walking Foot, 1/4" Free Motion Foot, 25/6/2Year Brother Manufacturer's Warranty*, 7mm Long Straight Stitch, Pin Feed comes up from Underneath the Needle Plate, Auto Needle Threader, Automatic Thread Trimmers Button, Knee Lift Lever, Drop Feed for Free Motion, Gathering Attachment.

  * Synchrony Bank Sewing & More Fixed Payments 0% No Interest Financing with approved credit! Click HERE to Apply Online for Synchrony Bank Sewing and More Credit Card Approval to use for Online Checkout or in AllBrands stores

  Brother Premium Warranty 2 years parts and labor, 6 years electronic parts, 25 years metal casting..



  From John M. Douthat, Founder of AllBrands:

  ""AllBrands is a Brother Authorized Dealer and ASC Authorized Service Center for warranty repairs. We give unlimited tech support by email, fax, phone, text and cell, plus service in our shop and referral to nearest ASC. This is a premium service that mass merchants can't offer, as they simply don't have the tech service or repair departments for your equipment. They are unable to help you directly, only referring your operational, mechanical or electronic questions back to Brother customer service desk—not their mechanics—instead of taking care of the problems themselves. Brother and customers should expect that any problems you might have will be taken care of by the dealer who sold you the equipment, not simply by referring your requests back to the manufacturer, and this is something we guarantee on our Brother machines."

  Brother PQ1500S/L is the same as Babylock Baby Jane BL500A by Brother which is selling in dealer stores for $999+

  *Save up to $240 more on the additional purchase of 5 to 10 Year Extended Parts and Labor Repair Warranty, Arrow Gidget Portable Folding Table and Chair, 12 Poly Thread Packs, 100 Organ 15x1 Needles, 100 Metal Bobbins, Deluxe Carrying Case.



  "I want to thank you very much for your trouble shooting emails. You are certainly more helpful than Brother Customer Service. They just tell you to take it to an Authorized service repair. I have bought 3 sewing machines from your Company , and would not hesitate to recommend Allbrands to anyone looking for a sewing machine. Your shipping and Customer Service is great! Lauretta D, Wallkill, NY"


• High speed straight stitch machine with maximum of 1,500 stitches per minute

• Expanded work area for large projects—more than 6" height and 9" width in the fabric bed area

• Heavy-duty construction for increased stability and penetrating power

• Up to 7 mm stitch length for perfect stitch lengths or basting

• Exclusive pin feed mechanism to prevent slippage

• Knee lifter and extension table for quilting and fabric management of bulky projects

• Built-in telescopic thread stand for cone thread usage

• Full range feed pressure adjustment and 4 feed dog height settings for different fabric weights

• Tension adjustment dial for different fabric and thread weights

• Exclusive fabric separator feature joins lightweight linings to materials such as velvets and eliminates the puckering

• Easy to use foot lift operation-the lower feed dog drops automatically when the presser foot is lifted for easy fabric insertion

• Removable knee lift enables you to lift your presser foot leaving both hands free for fabric handling

• The feed dog adjustment knob lowers the feed dogs below the fabric plate for freemotion sewing (drop feed control)

• Exclusive F.A.S.T. automatic needle threader saves time and your eyesight

• Built-in automatic thread cutter activates with the touch of a button both top and bottom threads are neatly cut and threads are instantly reset for the next sewing operation

• Needle positioning mechanism lets you control needle up after needle stops down

• Eliminates the need to manually rotate the balance wheel to lower or raise the needle during a continuous stop and start sewing operation

• Optional 11" x 23" extension table is included on the Brother PQ-1500S model



  This is a complete, 36-minute instructional YouTube video from Brother on the PQ1500SL model. If you do not speak the language, please adjust the volume with the speaker button to the bottom-left of the video, as this film is from one of Brother's factories oversees, and a similar video is not yet available in English.





  This is a 6-minute instructional YouTube video from Brother on the PQ1500S model also in a foreign language. Please adjust the volume with the speaker button to the bottom-left of the video, as a similar video is not yet available in English.



  Brother PQ1500SLDemonstration by Angela Wolf

  *Includes Brother Premium 25 Year Head, 6 Years Electronics, 2 Year Parts and Labor Warranty

  New Zealand Review of Brother PQ1500, Juki TL2010, Janome 1600P (Pfaff Hobby Mega Quilter, and Viking Mega Quilter)

  Pin Feed Video 4.26 Minutes



• Optimum stitch control, width and length

• Optional BERNINA Stitch Regulator

• Automatic one-step buttonhole

• Wide range of stitches

• Up to 900SPM Stitches Per Minute

• 100 create and save stitch combinations

  The BERNINA 530 boasts an extensive repertoire of utility and decorative stitches whose properties can be individually set. Stitch length and width as well as 11 different needle positions can be freely modified, and either temporarily or permanently saved to the 530’s memory. The BERNINA 530 is therefore up to the challenge of a wide range of tasks, and provides you with optimum control over your sewing projects. Stitch parameters can be individually matched to the fabric and the intended effect, so that you always achieve your desired result when sewing and quilting. The BERNINA 530’s clearly laid-out control panel enables quick access to all stitch patterns and settings, including reverse and mirror function, manual or automatic buttonhole, and much more. Clever, practical and flexible – the ideal sewing machine for ambitious sewers.

  Bernina 530 Review

  BERNINA 530 and 550 QE: getting started and prepared for sewing. In the first part of the new BERNINA 530 and 550 QE tutorial you will get familiar with your new BERNINA sewing machine. We will show you how to prepare and use the basic features and the accessories for sewing and quilting. You will learn how to turn on the machine and plug in the foot control, change a presser foot, prepare the bobbin and thread the machine. Prepare youself for an unforgettable sewing adventure!


  The BERNINA 530 (BERNINA 5 Series). An intuitive sewing machine for creative people with high expectations: the BERNINA 530 offers a range of functions that simplify sewing and put you in control. Whether altering the stitch length, stitch width or needle position or even creating custom combinations, you'll appreciate the convenience of a machine that remembers the stitch details for you. Discover the new BERNINA 5 Series and the many ways it will inspire you to write your own story.


• High speed straight stitch machine with maximum of 1,500 stitches per minute

• Expanded work area for large projects—more than 6" height and 9" width in the fabric bed area

• Heavy-duty construction for increased stability and penetrating power

• Up to 7 mm stitch length for perfect stitch lengths or basting

• Exclusive pin feed mechanism to prevent slippage

• Knee lifter and extension table for quilting and fabric management of bulky projects

• Built-in telescopic thread stand for cone thread usage

• Full range feed pressure adjustment and 4 feed dog height settings for different fabric weights

• Tension adjustment dial for different fabric and thread weights

• Exclusive fabric separator feature joins lightweight linings to materials such as velvets and eliminates the puckering

• Easy to use foot lift operation-the lower feed dog drops automatically when the presser foot is lifted for easy fabric insertion

• Removable knee lift enables you to lift your presser foot leaving both hands free for fabric handling

• The feed dog adjustment knob lowers the feed dogs below the fabric plate for freemotion sewing (drop feed control)

• Exclusive F.A.S.T. automatic needle threader saves time and your eyesight

• Built-in automatic thread cutter activates with the touch of a button both top and bottom threads are neatly cut and threads are instantly reset for the next sewing operation

• Needle positioning mechanism lets you control needle up after needle stops down

• Eliminates the need to manually rotate the balance wheel to lower or raise the needle during a continuous stop and start sewing operation

• Optional 11" x 23" extension table is included on the Brother PQ-1500S model



  This is a complete, 36-minute instructional YouTube video from Brother on the PQ1500SL model. If you do not speak the language, please adjust the volume with the speaker button to the bottom-left of the video, as this film is from one of Brother's factories oversees, and a similar video is not yet available in English.





  This is a 6-minute instructional YouTube video from Brother on the PQ1500S model also in a foreign language. Please adjust the volume with the speaker button to the bottom-left of the video, as a similar video is not yet available in English.



  Brother PQ1500SLDemonstration by Angela Wolf

  *Includes Brother Premium 25 Year Head, 6 Years Electronics, 2 Year Parts and Labor Warranty

  New Zealand Review of Brother PQ1500, Juki TL2010, Janome 1600P (Pfaff Hobby Mega Quilter, and Viking Mega Quilter)

  Pin Feed Video 4.26 Minutes

  Grace Cutie
  Join Grace Cutie Quilters Facebook Discussion and Sharing Group for User Experiences, Handles Options, Etc.

  In Stock! This compact frame allows you to do everything a ten or twelve-foot frame can do for a fraction of the space and cost. Your Quilting, Anytime. Anywhere. 5 min setup & take down
  Simple & portable. Table shown Optional, not included.

  * Synchrony Bank Sewing & More Fixed Payments 0% No Interest Financing with approved credit! Click HERE to Apply Online for Synchrony Bank Sewing and More Credit Card Approval to use for Online Checkout or in AllBrands stores

  Optional Carriage with Front and Back Handles for Cutie frame if you don't want to use the underneath handles that come with the Cutie carriage for home sewing machines







  How to Quilt on the Cutie Frame Video



  New from Grace! A portable table top frame for sit down or stand up operation with front that will take up to Qnique 19 longarm machines in addition to your domestic portable sewing machine. If you've ever have wanted to try quilting on a frame but didn't have space or didn't want to invest that much money, then the Cutie Tabletop Fabric Frame from Grace Company is the answer to your woes. This compact frame allows you to do everything a ten or twelve-foot frame can do for a fraction of the space and cost. The Cutie can handle king size quilts and can be stored away when you are through. You don't have to have a dedicated space to set up the Cutie; all you need is a flat surface that is at least 48" long by 38" wide. Laminate countertops, wood surfaces, or plastic tables will all support the frame. You also don't need to worry about the Cutie scratching surfaces or sliding around. The frame's base has a thick rubber padding that "grips" surfaces and prevents movement. Don't let quilting tie you down, and instead, get started on your dream projects with the Cutie Tabletop Fabric Frame today! (Machine not included)

  Adjustable in or out handles work both in front and back of frame. Table shown is not included.

  You will likely need an extension for the foot control cord on your home sewing machine if the foot control does not reach the floor or if moving the machine moves the foot control. The other option is a Grace Remote Speed Control for compatible machines list: Click here to see the list of compatible machines. Currently the Cutie comes with just the single prong extension cable. Eventually, they are going to include 6 cables with each frame. It will include 1200mm (3.97’) cables, the cable already included, a TRS (stereo) Extension Cable, a Custom Barrel Extension Cable, an Angled Barrel jack Extension Cable, a HD9 Foot Pedal Extension cable, and a 3 Prong Extension Cable.

  PLEASE NOTE: the free foot control extension cord included has to be tested with single prong jacks on machines. We cannot guarantee that it will work, even on computer sewing machines. Please contact us with any questions.

  Your table needs to be a minimum of 24" deep by 48" wide. Optional metal table with 12" sit down operation height adjustment, this table is designed for sit down or stand up operation. Will do up to king size depending on thickness of quilt sandwich. Optional Speed Control under Recommended Accessories for compatible home machines that are listed HERE










  For many quilters, space and quilt size can be a large issue. The Cutie Frame can fit on any flat surface, allowing for use almost anywhere, and like the Hoop-Frame it can make any size quilt. Once a project is done for the day, it is easily stored in a closet until it is needed again.

  This frame fits at a price point for people who love quilting, and brings with it all the possibilities of free-motion quilting.

  While your customers will love its easy storage ability, the Cutie Fabric Frame can be broken down for use while travelling or on vacation.

  The Cutie Fabric Frame is a great accessory for sewing machines, allowing any sewer, artist or crafter to embellish their stitching on any fabric project.

  Space-Saving
  Cutie is a revolutionary frame that's perfect for those who want to use a quilting frame, but don't have the room for a larger model. The Cutie can fit on the kitchen table, your coffee table, or any other flat surface—no dedicated room or space required.

  Affordable
  The Cutie is the perfect free-motion quilting system for someone just starting out. Get a free-motion quilting system for under $1000! There's no need to buy an expensive quilting machine either, you can use any machine that fits this frame.

  Easy Storage
  Thanks to its small size, the Cutie can fit anywhere and can be stored easily. Simply break down the frame per the instructions and easily store the Cutie in a closet when not in use.

  Free Motion
  With the Cutie's premium dual-track system, free motion quilting has never been easier! Your sewing or quilting machine will effortlessly glide over the fabric in any direction. Easily quilt loops, arches, straight lines, and a multitude of other designs on the Cutie.

  Cross Compatible
  Grace's Cutie Tabletop Fabric Frame is compatible with almost any machine. The frame's top plate can accommodate any home machine that's less than 11-1/2" thick and is adjustable to fit sewing machines with up to 19" of throat space. So easily pair this frame with your longarm, midarm, or domestic machine.

  Storage and Accessibility
  Weighing an estimated 30-pounds, you can easily take this frame to classes or guild meetings. When you are ready to store it away, place it under a bed or vertically in a closet. With all the moving you can do with the Cutie Frame, it was designed with durability in mind, and it has additional corner braces and aluminum extrusions to make the structure more sturdy.

  Some of its key benefits are:

  1. It can fit on any sturdy flat surface, like a sewing table, kitchen/dining table, countertop, or foldable table for easy access to quilting anywhere.

  2. It's light and easy to maneuver for easy storage, and can be broken down for transport to different locations and even taken on vacation or quilting outside the home.

  3. With it's size and price point, the Cutie can be enjoyed, not just by quilters, by any crafter or fabric enthusiast that wants to add free-motion artistic stitching to their projects.

  4. The Cutie can fit any machine that our Q-Zone Hoop-Frame can, this includes almost any domestic quilting machine and our Q'nique 15 and 19 machines.


• Large, bright Greyscale Active Matrix Touch Screen: The same user-friendly navigation as our top-of-the-line Memory Craft with easy menus and instructions

• 98 Decorative and Utility Stitches

• Runs twice as fast as the Memory Craft 9000

• On Screen Editing - point, drag and drop designs to create your own designs on-screen.

• 2-step conversion from sewing to embroidery

• Import your designs from ATA PC Cards, PC Design Cards; OR choose from the 90 built-in designs

  Embroidery Features:

• Instant switch-over to/from regular sewing

• PC-link via ATA card (FLUSH CARD)

• Max. embroidery size 5.5"X 7.9" (140mm x 200mm)

• Embroidery speed 650spm

• Built-in designs: 90

• Monograming fonts:3 fonts plus 2 and 3 letter monograming

• Change colors to favorite thread ( Janome, Robison- anton, Madeira, Mettler)

• Embroidery area tracing

• Easy drag & drop for editing, placement

• On board resize

• Image rotation

• Image flip

• Time indicator* Stitch counter

• Zoom in & out

• Hoop Large 5.5 X 7.9 and 5 X4.3 included

  General Features:

• Backlit LCD touchscreen

• MY SET screen controls

• Multi-language designation

• Upgradeable via software

• Built-in memory

• Upper thread, bobbin thread, and presser foot sensors

• Automatic thread tension control

• Automatic drop feed mechanism

• Easy access accessory compartment in top lid

• One-piece sewing light

• Built-in needle threader

  Sewing Features:

• 98 Decorative and Utility stitches, plus 7 buttonholes

• Regular sewing speed: 820 spm with variable speed control

• Twin needle guard

• Start/stop sewing button

• Instant switch-over to/from embroidery to/from regular sewing




  Click HERE for Brochure on Janome Memory Craft MC9500 Sewing and Embroidery Machine

  Janome Memory Craft MC9500 Instruction Book Operating Manual ENGLISH

  Click here to view a detailed chart of the Memory Craft 9500

  Click here for Janome's Free Main PC Board Upgrade Version 1.10

  Download the design menus for the MC9500's built-in embroidery designs:

  Small designs PDF (1.1 MB) There are 60 small designs up to 4".
  Large designs PDF (2.34 MB) There are 30 large designs up to 8"

  Click Here to Download the Memory Craft 9500 Update to Version 1.11, Improves minor issues in Version 1.1 Via Janome.com Website
